CHB with CAD is a  common combination especially in the elderly.

Which will you Intervene first ?  Is the AV block related to CAD  ?

How to differentiate Ischemic from degenerative AV block ?

Differentiating is often difficult.Even coronary angiogram may not answer the query unless it is totally normal . For AV block to occur usually  LCX / RCA lesion is required.  LAD lesion in isolation are rare to cause CHB .

How often re-vascularisation  reverses  ischemic CHB ?

Logically  you expect more reversals.In real world it rarely happens.

Therapeutic options in combined CAD and CHB

  1. PCI and pace maker in the same sitting .
  2. PCI first followed by pace-maker at a later date.
  3. Pace maker first followed by PCI at a later date if required.
  4. CABG  and epicardial pacemaker ( best option In all critical TVD and CHB)
  5. Pace maker followed by CABG later
  6. Pacemaker followed by medical management (CHB with Insignificant CAD)

Can worsening of ischemia  occur after pacemaker  ?

Very much possible . Since the patient  has been benefited by low heart rate in terms of MVO2 consumption .(Inserting a pacemaker  is  like sudden withdrawal of beta blocker !)

Rate adoptive pacing can confer chronotropic competence which  may bring back the angina.So,what was a insignificant lesion  can become hemodynamicaly relevant  and  may require  angioplasty  later.

*The above clinical issue is applicable  for sinus node dysfunction and CAD as well.

Final message

There is no  fixed rule in the management strategy in combined  CHB and CAD .

Generally , electrical  therapy  should be given preference .Symptom guided approach  may be practical.

In this scientific era , one may argue to deal both issues  together by simultaneous  PCI and pacemaker ,  still  option 3 and 6  remain clear  favorites !

If angina  occurs  even in  baseline bradycardia  it is obvious the obstructive CAD  is  significant and needs immediate fixing .

Finally , though it looks an attractive  concept , It is very rare for CHB  to get reverted by PCI or CABG.









Read Full Post »

All left to right shunts are  acyanotic heart disease to begin with. Cyanosis appears if there is progressive PHT and reversal of shunt .We know this happens late in ASD.(third decade)

It is important to remember some of the  patients  with large ASD  can show significant desaturation without severe pulmonary HT.  This should not be mistaken for Eisenmenger reaction.

How ?

In  any large ASD ,

  • IVC blood can stream into LA by hitting preferentially the lower part of IAS.( It is the old fetal route that heart does not forget  and indulges whenever the  local hemo-dynamics permits !)
  • During straining , (Valsalva and equivalents)  right atrial pressure can exceed LA and small amount of shunts occur across RA.
  • ASD is often (15%) associated with systemic venous anomaly. The common one is persistent LSVC.  LSVC  is usually connected to coronary sinus . If it has a communication with LA (Un-roofed CS) , there can be significant cyanosis .
  • Further , a large ASD can act as a single atrium and considerable mixing happens and cyanosis results.

Finally ,two conditions should always be considered

  • ASD if associated with VPS auguments R-L shunt .
  • TAPVC can be mistaken for Eisenmengerisation of  ASD in bedside which presents as clinical signs of ASD + Cyanosis

* It is useful to recall ,even PFOs can shunt right to left at times of extreme RA pressures like during PEEP ventilation and orthostatic  deoxia in sick ICU patients are reported (If PFO can shunt R-L , why not huge ASD ?)

Final message

Cyanosis  in ASD is not always  an ominous sign .There are few important causes other than Eisenmenger. Though it  occurs intermittently , persistent mild desaturation is also possible.

Read Full Post »

Any new ST depression occurring during  EST is sine qua non for inducible ischemia.But,this rule does not uni-formally apply  in all 12 leads .ST depression occurring is certain leads is more important. While severe global ischemia can depress  ST segment  in most leads ,factually  only the leads V 5 and V6  predict true Ischemia.This because , bulk of LV muscle mass faces these two leads.

Isolated ST depression in inferior leads  during exercise

  • Is a frequent issue occurring at the peak exercise.
  • Is least predictive of significant CAD.
  • The exact mechanism is not clear.
  • Some continue to  believe it is indeed significant .
  • We have  observed  isolated  ST  depression > 2mm in inferior leads with significant CAD.
  • What really matters is the quantum of ST depression , symptoms, and exercise time and preexisting CAD .

Probable mechanism

  • Apart from true ischemia ,ST depression may indicate relative sub endocardial strain rather than ischemia.(By the way can simple stretch can cause ST depression ?)
  • The Infero posterior surface of heart represent  right ventricle .RV volume overlooked peaks exercise.Some think it represents acute raise in RV load during peak exercise.

How to report such EST ?

You can report it as such,  what you have observed.

  • ST depression noted in Inferior leads at peak exercise.
  • Mention whether it was angina free,
  • At what METS,
  • Total exercise time .

If you are statistically inclined  you can also mention the likely hood of CAD by positive predictive value (PPV) of the test (Low with isolated Inferior ST depression )

If you are really confused , and do not want to scratch your brain we have the most convenient terminology  invented by cardiac physicians ie Borderline EST, or Mildly positive EST “

Should we do Angiogram for such patients ?

In this era of catching normal people  who attend master health check ups  for a day care CAG  . . . it is not all  a crime to do angiogram in a  patient who shows suspicious  ST depression in three of his leads (2,3,AVF) especially if he also complains of vague chest pain.

Alternate investigation

Of course , we  always have the luxury of using  MDCT  that can stunningly  photograph the coronary arteries.

It is a mystery investigation, if it comes entirely normal every one is happy.Even slightest  defects in the photography  has a potential to confuse both physician and the patient .

What I do ?

I hesitate to  do routine CAG  if ST depression occur exclusively at  peak exercise beyond 10-12  METS , which disappear fast.(Many times we can apply this rule  to classical ischemic ST depression of lead V4 as well !)

ST  depression  in any leads (with any degree) following an episode of  ACS seems to be important.

Related topic

Read Full Post »

The WordPress.com  prepared a  official 2013 annual report for this blog.

Here’s an excerpt:

The Louvre Museum has 8.5 million visitors per year. This blog was viewed about 540,000 times in 2013. If it were an exhibit at the Louvre Museum, it would take about 23 days for that many people to see it.

Click here to see the complete report.



Read Full Post »

Dear friends,

It all started in 2008. This is  6th year of my attempt to share knowledge in cardiology.The followers of my blog is the only  strength that sustain my writing .

Wishing you all a Happy , wonderful  and  a prosperous , New year 2014

But . . . please be reminded we don’t require a New year to bring a bout of happiness , it is sitting right in our minds every day  !

On this day let me quote my most revered quote of Hemmingway.

Ernest hemmingway quotes

Ernest Hemmingway the Nobel laureate  who was born in USA, Lived in Paris , fought in world war 2 , lived in the deep forests of Africa with wild animals during the fag end of his life .He had a Intimate relationship with Cuba,  made a passionate appeal to end the man made disaster called wars in this planet , before his life ended in 1961.

To connect with  this noble (Nobel ) soul  reach through Wikipedia Link

Read Full Post »
